The HSCo HSC-LCD 7 is an aluminium load cell for crane and hanging scales from 100 to 500 kg. It is a flat plate, 146 × 46 mm, with a 19 mm hole at each end, 116 mm apart, for the top and bottom fittings. It is accurate to ±0.05% of full scale, takes 150% of its rating safely, is sealed to IP67 or IP68 and is made to OIML R60.
Why scale makers choose it
- Made for crane and hanging scales from 100 to 500 kg.
- Light aluminium plate with a fixing hole at each end.
- Accurate: ±0.05% FS total error.
- Overload margin: safe 150%, limit 180% of full scale.
- Sealed to IP67 or IP68; made to OIML R60.
Specifications
| Model | HSC-LCD 7 |
|---|---|
| Type | Crane / hanging scale load cell, plate type |
| Capacities | 100 – 500 kg |
| Sensitivity | 0.8 ± 0.1 mV/V |
| Total error | ±0.05% FS |
| Creep | 0.02% FS (30 min) |
| Zero balance | ±3% FS |
| Temperature effect | Zero and span ±0.02% FS / 10 °C |
| Temperature range | Compensated −10 to +40 °C; operating −30 to +70 °C |
| Overload | Safe 150% FS; limit 180% FS |
| Excitation | 10 – 12 V DC recommended; 15 V DC max |
| Impedance | Input 350 ± 10 Ω; output 350 ± 3 Ω |
| Insulation | ≥ 5,000 MΩ at 100 V DC |
| Protection | IP67 or IP68 |
| Material | Aluminium |
| Size | 146 × 46 mm; two 19 mm fixing holes 116 mm apart; two 5 mm holes |
| Wiring | Exc + red, Exc − black, Sig + green, Sig − white, shield yellow |
| Standard | Made to OIML R60 |
| Warranty | 1 year |
Which crane scale load cell?
For 1 to 10 t with a shackle and hook, see the HSC-LCD 2 or the HSC LCD-1. For a platform scale, the single point platform load cell. Browse all load cells.
Where it is used
Building or repairing crane and hanging scales up to 500 kg.
Questions buyers ask
From 100 to 500 kg. Tell us the capacity you need.
Aluminium, sealed to IP67 or IP68.
Red and black are the excitation (+ and −), green and white the signal (+ and −), and yellow the shield.
