Video Spectral Comparator HSC-VSC – Forensic Document Examination
Price on Request
Video spectral comparator for questioned-document examination: UV (254/312/365 nm), IR (880–950 nm) and visible light, 10×–100× magnification, Full HD live video, image capture and measurement software.
The HSC video spectral comparator (VSC) examines documents under ultraviolet, infrared and visible light at up to 100× magnification, so that alterations, forged entries, hidden security features and differences between inks show up on screen. It is used by forensic laboratories, banks, passport and security agencies, and quality-control departments that check printed documents.
What it helps you find
- Alterations and erasures: changes invisible in daylight often show under UV or IR.
- Different inks: two inks of the same colour can respond differently to infrared.
- Security features: UV-reactive fibres, inks and watermarks on currency, passports and certificates.
- Counterfeits: side-by-side comparison with a genuine document.
Specifications
| Optics | High-resolution video optics, 10× – 100× magnification |
|---|---|
| UV light | 254 nm, 312 nm, 365 nm |
| IR light | 880 – 950 nm |
| Visible light | Variable intensity |
| Filters | Multi-spectral filter set |
| Display | Full HD monitor with live video |
| Image capture | Integrated digital camera with documentation software |
| Software | Real-time enhancement and contrast; line-width, spacing and feature measurement; image storage, annotation and reports |
| Stage | Motorised X-Y or manual stage with fine positioning |
| Focus | Coarse and fine |
| Power | 220 – 240 V, 50/60 Hz |
| Construction | Robust, anti-vibration body for forensic labs |
| Options | Polarising filters for ink and material analysis; remote control and network access for several users |
| Warranty | 1 year |
Questions buyers ask
To examine documents under UV, IR and visible light for alterations, forgeries, ink differences and security features.
UV at 254, 312 and 365 nm, IR from 880 to 950 nm, and variable visible light.
Yes. An integrated camera and software capture, annotate, store and report images.
From 10× to 100×.
Yes, with the optional remote control and network integration.
Ask for a quotation
Call or WhatsApp +91-7045922250 or email hsc@hindustanscale.com with the documents you examine and whether you need the motorised stage or network access. Hindustan Scale Company, Mumbai, since 1955.
