Model | HSC-I-CIBODIRI-70BV | HSC-I-CIBODIRI -150BV | HSC-I-CIBODIRI -250BV | |
HSC-I-CIBODIRI -70BLT | HSC-I-CIBODIRI -150BLT | HSC-I-CIBODIRI -250BLT | ||
Cycle Mode | Forced convection | |||
Function | Temp. Range | -10-65℃ | ||
Temp. Resolution Ratio | 0.1℃ | |||
Temp. Motion | High Temp.: ±0.5°C Low Temp.: ±1℃ | |||
Temp. Uniformity | ±1℃ | |||
Structure | Inner Chamber | Mirror Stainless Steel | ||
Outer Shell | Cold rolling steel electrostatic spraying exterior | |||
Insulation Layer | Polyurethane | |||
Heater | Stainless steel heating tube | |||
Power Rating | 0.8kW | 1.0kW | 1.2kW | |
Compressor | Air cooled hermetic compressor | |||
Cryogen | R134a | |||
Defrost Structure | Double evaporator switching defrosting | |||
Test Hole | 43mm | |||
Controlled External Power Supply | Universal socket (one) Built in waterproof socket ( one ) | |||
Temp. Control Mode | BV: Color screen LCD program BLT: 5.0 inch touch screen | |||
Temp. Setting Mode | Touch button setting or Touch screen type | |||
Temp. Display Mode | Measuring temperature: LCD upper screen; setting temperature: LCD lower row | |||
Timer | 0-99.9h 30Segment | |||
Operation Function | Program operation | |||
Sensor | PT100 | |||
Additional Funciton | BV model: LED light, Deviation correction, Menu key lock, Power failure parameter memory BLT model additional character: loop self-diagnosis Over temperature alarm, digital temperature limiter | |||
Safety Device | Over temperature alarm, digital temperature limiter | |||
Specification | Inner Chamber Size(W*L*H)(mm) | 420*350*500 | 500*500*600 | 600*500*840 |
Exterior Size (W*L*H)(mm) | 580*610*1190 | 660*760*1290 | 760*760*1530 | |
Packing Size (W*L*H)(mm) | 706*698*1358 | 856*778*1458 | 878*865*1698 | |
Volume | 70L | 150L | 250L | |
Load Per Rack | 15kg | |||
Shelf Number | 9 | 12 | 18 | |
Shelf Space | 35mm | |||
Power Supply Current Rating | AC220V/2.3A | AC220V/3.6A | AC220V/5.5A | |
NW/GW (kg) | 69/92 | 86/114 | 100/139 | |
Accessory | Shelf | 2 | ||
Shelf Frame | 4 | |||
Optional Accessories | Spare shelf, RS485 interface, printer, remote control, U-disk storage | |||
