The HSCo CRHHRDJH is the CRHHR heat resistant crane scale fitted with a double J hook, for weighing hot loads in steel, aluminium, copper, glass and chemical plants and thermal power stations. A heat shield protects the die-cast body, which is rated for heat up to 1,000 °C. It reads on an extra-bright jumbo green display, a jumbo remote handles tare, calibration and switching off from a safe distance, and a stability chip steadies readings on moving loads. It comes in 3, 5, 10, 20 and 50 tonnes and is stamped by the Legal Metrology department.
Why steel plants choose it
- Double J hook at the bottom, shackle at the top.
- Heat shield, rated up to 1,000 °C.
- Jumbo green display, extra bright, wide viewing angle.
- Jumbo remote with tare, calibration and an OFF button.
- Stable on moving loads: stability chip and high internal counts.
- Stamped by the Legal Metrology department.
Specifications
| Model | CRHHRDJH (CRHHR series with double J hook) |
|---|---|
| Capacities | 3,000, 5,000, 10,000, 20,000, 50,000 kg (choose above) |
| Body | Die-cast, 90+ micron powder coating; heat shield; rated up to 1,000 °C |
| Load cell | Stainless-steel composite, steel alloy; rust and water resistant; 200% overload; life up to 10 years |
| Rigging | Shackle top, double J hook bottom |
| Display | Extra-bright jumbo green LED, wide viewing angle; the decimal point shows when the weight is stable |
| Remote | Jumbo remote: tare, calibration, OFF; dust and water resistant |
| Electronics | Stability chip for moving loads; high internal counts; water-resistant PCB; direct charging |
| Power | 230 V AC ±10%, 50 Hz / 9 V DC, 1 A; rechargeable battery, fast charge (backup time depends on the model) |
| Options | Remote display (green 20 mm LED, up to 200 m); handheld display with thermal printer (up to 30,000 records, up to 30 m); jumbo display (4-inch, red or green, up to 20 m) |
| Certification | Legal Metrology stamped; ISO 9001:2015 certified company; Made in India |
| Warranty | 1 year |
Which heat resistant crane scale?
With a standard hook, see the CRHHR heat resistant crane scale. In stainless steel for heat up to 1,600 °C with a double J hook, the CRHSSDJH; with a heat shield on a red body, the HSC-NZS-DJH. Browse all crane scales.
Where it is used
Steel, aluminium, copper, glass and chemical industries, thermal power plants and heavy industries.
Questions buyers ask
It has a heat shield and is rated for heat up to 1,000 °C.
3, 5, 10, 20 and 50 tonnes.
Yes. The jumbo remote tares, calibrates and switches off the scale.
Order or ask for a quotation
Call or WhatsApp +91-7045922250 or email hsc@hindustanscale.com with the capacity you need. Hindustan Scale Company, Mumbai, since 1955.
