Laboratory Water Bath 5-22 L, ±0.2 °C, PID

Laboratory Water Bath HSC-WB1000 – 5 to 22 L, up to 100 °C, ±0.2 °C

Price on Request

Standard lab water bath: RT+5 °C to 100 °C, ±0.2 °C, PID digital control, stainless chamber, 1–5,999 min timer, quick drain. 5, 12 and 22 L models, one with circulation pump.

Price on Request

Ask for a quotation

Or call +91-7045922250 or use the WhatsApp button.

The HSC-WB1000 series standard water bath keeps samples, reagents and tubes at a steady temperature from 5 °C above room temperature up to 100 °C, within ±0.2 °C. It has a stainless-steel chamber and heater, PID digital control on a large LCD, a 1–5,999 minute timer and a quick-drain valve. Four models run from 5 to 22 litres, one with a circulation pump.

Why labs choose it

Stable temperature. PID control holds ±0.2 °C with 0.1 °C resolution.
Hygienic chamber. Stainless steel with rounded corners that are easy to clean, and a quick-drain valve.
Protects your tubes. A stainless bottom plate keeps tubes off the heater and sensor.
Even heating. The pump model circulates water for uniform temperature.
Safe to leave. Over-temperature protection (DIN 12880), overcurrent alarm, deviation alert, preset on/off timer and auto-restart after a power cut.

Specifications

Model	HSC-WB1005	HSC-WB1012	HSC-WB1022	HSC-WB1022P
Volume	5 L	12 L	22 L	22 L + pump
Power	500 W	800 W	1,000 W	1,000 W
Inner size (mm)	280 × 130 × 150	280 × 220 × 150	490 × 300 × 150	490 × 300 × 150
Outer size (mm)	345 × 200 × 340	345 × 285 × 355	545 × 343 × 355	545 × 343 × 355
Lid	2-hole	4-hole	6-hole	6-hole
Weight	5 kg	12 kg	18 kg	19 kg

Temperature range	Room temperature +5 °C to 100 °C
Fluctuation / resolution	±0.2 °C / 0.1 °C
Control	PID digital, large LCD
Timer	1 – 5,999 minutes
Options	RS-485 or USB output for data logging
Warranty	1 year

Where it is used

Warming reagents, incubating samples, thawing, and routine heating in pharma labs, academic research, clinical diagnostics and QC. For shaking during incubation, see the shaking water bath, or browse all temperature control equipment.

Questions buyers ask

What temperature range does it cover?

From 5 °C above room temperature up to 100 °C.

How stable is the temperature?

Within ±0.2 °C.

Which size should I choose?

5, 12 or 22 litres, by how many tubes or flasks you use; choose the 22 L pump model for the most even temperature.

What happens after a power cut?

It restarts automatically with your settings.

Ask for a quotation

Call or WhatsApp +91-7045922250 or email hsc@hindustanscale.com with the model and quantity. Hindustan Scale Company, Mumbai, since 1955.

Click to enlarge

Back to products

Compare

Description

Model	HSC-WB1005	HSC-WB1012	HSC-WB1022	HSC-WB1022P
Volume	5 L	12 L	22 L	22 L + pump
Power	500 W	800 W	1,000 W	1,000 W
Inner size (mm)	280 × 130 × 150	280 × 220 × 150	490 × 300 × 150	490 × 300 × 150
Outer size (mm)	345 × 200 × 340	345 × 285 × 355	545 × 343 × 355	545 × 343 × 355
Lid	2-hole	4-hole	6-hole	6-hole
Weight	5 kg	12 kg	18 kg	19 kg

Temperature range	Room temperature +5 °C to 100 °C
Fluctuation / resolution	±0.2 °C / 0.1 °C
Control	PID digital, large LCD
Timer	1 – 5,999 minutes
Options	RS-485 or USB output for data logging
Warranty	1 year
