High-Performance Gas Chromatograph- HSC – HPGC

Technical Specifications – High-Performance Gas Chromatograph (HPGC)

1. Model: HSC-HPGC Series

2. Type: Benchtop High-Performance Gas Chromatograph

3. Detector Options:

   • Flame Ionization Detector (FID)

   • Thermal Conductivity Detector (TCD)

   • Electron Capture Detector (ECD)

   • Flame Photometric Detector (FPD) (optional)

4. Temperature Control Range: Ambient +10°C to 450°C

5. Temperature Accuracy: ±0.1°C

6. Temperature Programming: Multi-step programmable with up to 20 ramps

7. Oven Cooling Rate: 450°C to 50°C in ≤ 7 minutes (forced air cooling)

8. Injection System:

   • Split/Splitless injector with electronic flow control

   • Injector temperature: Ambient +10°C to 400°C

9. Column Compatibility: Capillary, Packed, or Microbore columns

10. Carrier Gas: Nitrogen, Helium, or Hydrogen (as per method requirement)

11. Flow Control: Digital Electronic Pneumatic Control (EPC) for precision gas flow management

12. Detector Sensitivity:

    • FID: ≥ 2 × 10⁻¹² g/s (nC16)

    • TCD: ≥ 4000 mV·mL/mg (He, Butane)

13. Repeatability: ≤ 1% RSD for peak area

14. Display & Interface:

    • 7-inch touch screen / LCD display

    • USB / RS232 interface for PC data transfer

15. Software: Windows-based chromatography data system for acquisition, integration, and reporting

16. Power Supply: AC 220V ±10%, 50/60 Hz

17. Dimensions (Approx.): 600 × 500 × 450 mm

18. Weight: 25–40 kg (depending on configuration)

19. Applications:

    • Pharmaceutical and chemical purity analysis

    • Petrochemical and refinery testing

    • Environmental air and water sample analysis

    • Food and flavor component identification

    • Research and academic laboratories
