Precision Forced Air Drying Oven HSC-OF-S – 30 to 625 L, up to 300 °C
Price on Request
Precision forced-air drying oven: seven sizes from 30 to 625 L, room +10 °C to 300 °C, ±1 °C stability, ±2.5% uniformity, mirror-finish stainless chamber, rock wool insulation. For labs, pharma and R&D. 1-year warranty.
The HSCo HSC-OF-S series are precision forced-air drying ovens for laboratories, pharmaceutical and R&D work, and light industry. A fan circulates the air for even heat (±2.5% uniformity) from 10 °C above room temperature up to 300 °C, held within ±1 °C. The mirror-finish stainless-steel chambers come in seven sizes from 30 to 625 litres, for drying, sterilising and thermal testing.
Why labs choose the OF-S series
- Even heat. Forced-air circulation, ±2.5% uniformity.
- Steady. ±1 °C stability, 0.1 °C resolution.
- Seven sizes. 30, 45, 65, 85, 125, 230 and 625 litres.
- Clean chamber. Mirror-finish stainless steel (SUS304 on BE models).
- Well insulated. High-quality rock wool; stainless heating tubes.
- Vented. Ø35 mm top exhaust with test port; rear exhaust; dual exhaust on the 625 L.
Specifications
| Volume | 30 L | 45 L | 65 L | 85 L | 125 L | 230 L | 625 L |
|---|---|---|---|---|---|---|---|
| Model | HSC-OF-S30 / SBE30 | HSC-OF-S45 / SBE45 | HSC-OF-S65 / SBE65 | HSC-OF-S85 / SBE85 | HSC-OF-S125 / SBE125 | HSC-OF-S230 / SBE230 | HSC-OF-S625 / SBE625 |
| Circulation | Forced convection |
|---|---|
| Temperature range | Room +10 °C to 300 °C |
| Resolution / stability | 0.1 °C / ±1.0 °C |
| Uniformity | ±2.5% |
| Heater | High-grade stainless-steel heating tubes |
| Inner chamber | Mirror-finish stainless steel (SUS304 on BE models) |
| Outer body | Cold-rolled steel, electrostatic powder coat |
| Insulation | High-quality rock wool |
| Exhaust | Top Ø35 mm with test port; rear exhaust; dual exhaust on 625 L |
| Warranty | 1 year |
Which oven?
For temperatures up to 500 – 600 °C, see the HSC-OF-FA1000 forced air oven. For a compact 18 L oven, the HSC-HT1000 drying oven; for drying under vacuum, the vacuum drying oven. Browse all ovens and furnaces.
Questions buyers ask
Up to 300 °C, starting from 10 °C above room temperature.
30, 45, 65, 85, 125, 230 and 625 litres.
SBE models have a SUS304 stainless-steel inner chamber.
A fan moves the hot air around the chamber, so it heats faster and more evenly.
Order or ask for a quotation
Call or WhatsApp +91-7045922250 or email hsc@hindustanscale.com with the size you need. Hindustan Scale Company, Mumbai, since 1955.
