The WCS is HSCo’s electronic wheelchair scale with a single ramp. It has an extremely low platform and one ramp, so a patient can be wheeled on and weighed without leaving the chair. A handrail frame carries the indicator, which has LED displays on both sides. It comes in 200, 300, 500 and 1,000 kg, runs on mains or its rechargeable battery, and is supplied stamped by the Legal Metrology Department with the original certificate. It is made for hospitals, clinics and wellness centres.
Why hospitals choose the WCS
- Weigh without transfers. Roll the wheelchair up the ramp onto the low platform.
- Four capacities: 200, 300, 500 and 1,000 kg.
- Read from both sides. The indicator has bright LED displays front and back.
- Tare the chair. Weigh the empty chair once, then read the patient’s weight directly.
- Heavy-duty metal body with a 90+ micron powder coat.
- Works anywhere. Mains power or rechargeable battery, with sleep mode to save it.
- Government stamped, with the original stamping certificate.
Specifications
| Model | WCS |
|---|---|
| Capacity | 200 kg, 300 kg, 500 kg, 1,000 kg |
| Platform | Extremely low profile, with a single ramp for the wheelchair; handrail frame with the indicator on top |
| Display | Bright seven-segment LED, on both sides of the indicator |
| Functions | Tare, zero, auto zero tracking, auto calibration, auto power saving, sleep mode; digital overload indication |
| Body | Heavy-duty metal, 90+ micron powder coating |
| Load cells | Precision load cells; 200% overload |
| Power | 230 V AC ±10%, 50 Hz / 9 V DC; rechargeable battery (backup time depends on the model) |
| Working temperature | 0 – 40 °C |
| Options | Printer; Bluetooth; RS-232; USB; Wi-Fi; remote or Wi-Fi display; external indicator |
| Certification | Legal Metrology stamped (1-year stamping, original certificate supplied) |
| Warranty | 1 year |
Which wheelchair scale?
For a chequered-plate platform with ramps and steel side rails, see the PLCHQHWCSS wheelchair scale, or the PLCHQWC series. Browse all medical scales.
Where it is used
Hospitals, clinics, medical laboratories, wellness centres and the pharmaceutical industry.
Questions buyers ask
Does the patient have to get out of the wheelchair?
No. The chair rolls up the ramp onto the platform, and the patient is weighed sitting in it.
How do I get the patient's weight without the chair?
Weigh the empty chair and press tare; the display then shows only the patient’s weight.
Which capacity should I choose?
200, 300, 500 or 1,000 kg. Choose one above the heaviest patient plus the chair.
Is it stamped?
Yes. It comes stamped by the Legal Metrology Department, with the original certificate.
Order or ask for a quotation
Choose the capacity and add it to your cart, or call or WhatsApp +91-7045922250 or email hsc@hindustanscale.com. Hindustan Scale Company, Mumbai, since 1955.
