Key Features
PID Digital Temperature Control – Large LCD for precise, easy-to-read operation.
Wide Timer Range – Adjustable from 1 to 5999 minutes.
Built-in Water Circulation (HSC-WB1022P) – Ensures uniform bath temperature.
Corrosion-Resistant Construction – Stainless steel chamber and heater for durability and hygiene.
Rounded Inner Chamber – Easy to clean, no dead corners.
Stainless Steel Bottom Plate – Prevents tube contact with heater and sensors.
Quick-Drain Valve – Easy cleaning and maintenance.
Built-In Safety Features
Power Interruption Auto-Restart
Over-Temperature Protection (DIN 12880 Compliant)
Overcurrent Protection Alarm
Temperature Deviation Alert
Preset On/Off Timer
Optional Add-ons
RS-485 or USB Output Ports – For real-time data logging and system integration.
Technical Specifications – HSC-WB1000 Series
| Model No. | Chamber Volume | Power (W) | Temp. Range (°C) | Temp. Fluctuation | Resolution | Internal Dimensions (mm) | External Dimensions (mm) | Timer | Weight (Kg) | Lid |
|---|---|---|---|---|---|---|---|---|---|---|
| HSC-WB1005 | 5L | 500W | RT+5 ~ 100°C | ±0.2°C | 0.1°C | 280×130×150 | 345×200×340 | 1–5999 min | 5 | 2-hole |
| HSC-WB1012 | 12L | 800W | RT+5 ~ 100°C | ±0.2°C | 0.1°C | 280×220×150 | 345×285×355 | 1–5999 min | 12 | 4-hole |
| HSC-WB1022 | 22L | 1000W | RT+5 ~ 100°C | ±0.2°C | 0.1°C | 490×300×150 | 545×343×355 | 1–5999 min | 18 | 6-hole |
| HSC-WB1022P* | 22L + Pump | 1000W | RT+5 ~ 100°C | ±0.2°C | 0.1°C | 490×300×150 | 545×343×355 | 1–5999 min | 19 | 6-hole |
