Specification | ||||||
|
| Model | HSCM -P200PEN | HSCM -ORP200PEN | HSCM-C200PEN | HSCM-PC200PEN |
|
| pH/mV.°C | ✓ | – | – | ✓ |
| Parameter | mV(ORP).°C | – | ✓ | – | ✓ |
|
| Cond/TDS/Sal./Res.°C | – | – | ✓ | ✓ |
pH
| Measurement range | (-2.00 – 16.00)pH | ✓ | – | – | ✓ |
Resolution | 0.01 | ✓ | – | – | ✓ | |
Accuracy | ±0.01pH ± one digit | ✓ | – | – | ✓ | |
Calibration points | 1-3pts auto | ✓ | – | – | ✓ | |
ATC range | 0 – 60°C(32 – 140°F) |
| – | – | ✓ | |
ORP
| Measurement range | (-1000 – +1000)mV | ✓ | ✓ | – | ✓ |
Resolution | 0.1 | ✓ | ✓ | – | ✓ | |
Accuracy | ±0.1%F.S ± one digit | ✓ | ✓ | – | ✓ | |
|
| 0 – 19.99mS/cm, |
|
|
|
|
|
| Auto divided by range |
|
|
|
|
Conductivity
| Measurement | TDS:0-10.0ppt(Factor adjustable) |
|
| ✓ | ✓ |
range | Resistivity:50Ω·cm – 20MΩ·cm |
|
|
|
| |
| Salinity:0 – 10.0ppt |
|
|
|
| |
Resolution | 0.01/0.1/1 |
| – | – | ✓ | |
Accuracy | ±1.0% ± one digit |
| – | – | ✓ | |
Temperature | Measurement range | (0.0 – 60.0)°C/(32.0 – 140.0)°F | ✓ | ✓ | ✓ | ✓ |
Accuracy | ±0.2°C |
| ✓ | ✓ | ✓ | |
| Calibration reminder |
| ✓ | ✓ | ✓ | ✓ |
|
|
|
|
|
|
|
APP Features
| Sample ID |
| ✓ | ✓ | ✓ | ✓ |
Measurement alarm |
| ✓ | ✓ | ✓ | ✓ | |
Timing data storage |
| ✓ | ✓ | ✓ | ✓ | |
Diagram operation guide |
| ✓ | ✓ | ✓ | ✓ | |
Multiple display Model |
| ✓ | ✓ | ✓ | ✓ | |
Test kit
| Meter |
| ✓ | ✓ | ✓ | ✓ |
Probe (pre-installed) |
| PH1-S | ORP1-S | EC1-S | PC1-S | |
pH buffer solution: pH4.00/7.00/10.01, 30mL, one for each |
| ✓ | ✓ | ✓ | ✓ | |
3.0 mol KCI pH/ORP soaking solution, 10mL, 1 bottle |
| ✓ | ✓ | – | ✓ | |
Sample Vials: 30mL |
| 3 pcs | 1 pc | 2 pcs | 4 pcs | |
ORP Standard solution 222 mV, 30mL |
| ✓ | – | ✓ | ✓ | |
Standard Cond solution 1413µS/12.88mS/cm, 30mL, one for each |
| – | – | – | ✓ | |
pH buffer solution: pH4.00/7.00, 30mL, one for each |
| – | – | ✓ | ✓ | |
4×1.5V AAA alkaline batteries (pre-installed) |
| ✓ | ✓ | ✓ | ✓ | |
Lanyard |
| ✓ | ✓ | ✓ | ✓ | |
Hard carrying case (L/W/H: 28.0×23.0×8.2cm) |
| ✓ | ✓ | ✓ | ✓ | |
