The HSC-WXCSS series is HSCo’s heavy-duty crane scale for very large loads: a compact load link with a top shackle and a large safety hook that sits in the crane line, in 100, 150, 200 and 300 tonne models. The weight is sent wirelessly to a handheld indicator with a built-in printer, so the operator reads and prints each lift from a safe distance. It is used in steel plants, shipyards, docks, heavy fabrication and construction.
Why heavy industry chooses the WXCSS
- Very high capacities. 100, 150, 200 and 300 tonnes.
- Handheld indicator with printer. Prints weight slips, stores records, and comes in a carry case.
- Read it from a distance. Wireless indicator and remote, so nobody stands under the load.
- Steady on moving loads. A stability chip settles the reading.
- Strong load cell rated for 200% overload, with a life of up to 10 years.
- All-weather. Stainless-steel load link, water-resistant PCB, rust and corrosion-resistant coating.
Specifications
| Series | HSC-WXCSS |
|---|---|
| Capacities | 100 t, 150 t, 200 t, 300 t |
| Construction | Stainless-steel load link with top shackle and safety hook |
| Load cell | Steel alloy; 200% overload; life up to 10 years |
| Indicator | Handheld wireless indicator with built-in thermal printer; carry case |
| Remote | Range up to 10 m |
| Functions | Tare, zero, auto zero tracking, auto calibration, sleep mode; digital overload indication |
| Power | 230 V AC ±10%, 50 Hz / 9 V DC; rechargeable battery, charges without removing it (backup time depends on the model) |
| Working temperature | 0 – 40 °C |
| Options | Handheld display storing up to 30,000 records (range up to 30 m); remote LED display (20 mm digits, up to 200 m); jumbo display; Bluetooth; desktop printer; double J hook |
| Certification | Legal Metrology stamped; ISO 9001:2015 certified company; made in India |
| Warranty | 1 year |
Which crane scale?
For 2 – 100 t load links with a wireless handheld display, see the wireless dynamometer. For 3 – 20 t with a remote display, the CRHRD; for hot loads, the CRHHR heat-resistant crane scale. Browse all crane scales.
Where it is used
Steel plants, shipyards, docks and naval yards, heavy fabrication, construction and timber yards.
Questions buyers ask
100, 150, 200 and 300 tonnes.
Yes. The handheld indicator has a built-in printer for weight slips.
The remote works up to 10 m; the optional handheld display up to 30 m and remote display up to 200 m.
Yes, with Government of India stamping.
Order or ask for a quotation
Call or WhatsApp +91-7045922250 or email hsc@hindustanscale.com with the capacity and crane details. Hindustan Scale Company, Mumbai, since 1955.
