The HSCo general purpose dynamic checkweigher weighs every pack on a moving conveyor and rejects any that are under or over weight, without stopping the line. Three sizes cover products up to 1 kg, 5 kg and 10 kg, at belt speeds of 20 to 90 m/min, with a high-speed A/D sampling module, a 10-inch colour touch screen, 100 stored products and a choice of rejectors. The frame is SUS304 stainless steel.
Why production lines choose it
- 100% in-line weight check at 20 – 90 m/min.
- Three sizes: up to 1 kg, 5 kg or 10 kg per pack.
- Fine resolution: 0.1 g minimum scale.
- Choice of rejector: air blast, pusher, swing arm, flip-down or diversion.
- 10″ colour touch screen with 100 product presets.
- SUS304 stainless steel construction.
Models
| Size 210 | Size 300 | Size 400 | |
|---|---|---|---|
| Checking range | Up to 1,000 g | Up to 5 kg | Up to 10 kg |
| Accuracy | ±0.3 – ±1 g | ±0.5 – ±5 g | ±2 – ±10 g |
| Minimum scale | 0.1 g | 0.1 g | 0.1 g |
| Belt speed | 20 – 90 m/min | 20 – 90 m/min | 20 – 90 m/min |
| Product length / width | ≤ 280 / ≤ 200 mm | ≤ 300 / ≤ 290 mm | ≤ 450 / ≤ 390 mm |
| Weighing section (L × W) | 400 × 210 mm | 450 × 300 mm | 620 × 400 mm |
| Display | 10-inch colour touch screen |
|---|---|
| Control | High-speed A/D sampling module |
| Product memory | 100 presets |
| Rejectors | Air blast, pusher, swing arm, flip-down, diversion |
| Structure | SUS304 stainless steel |
| Power | AC 220 / 110 V ±10%, 50/60 Hz |
| Working conditions | 0 – 40 °C; humidity 30 – 95% |
| Warranty | 1 year |
Where it is used
Packing lines in any industry where every pack must meet its declared weight. See also the heavy-duty checkweigher; browse all checkweighers.
Questions buyers ask
It weighs every pack on the moving line and pushes out any that are outside the set weight limits.
20 to 90 metres per minute.
Up to 10 kg on the largest size.
Air blast, pusher, swing arm, flip-down or diversion.
Ask for a quotation
Call or WhatsApp +91-7045922250 or email hsc@hindustanscale.com with your pack size, weight and line speed. Hindustan Scale Company, Mumbai, since 1955.
